Geberit CleanLine80 Shower Channels, length 30-90cm (can be cut to length)

• Geberit CleanLine80
• 1 x Shower Channels
• For the drainage of floor-level showers
• For installation in the room or on the wall
• For installation in thin-bed mortar
• For bonded waterproofing
• Suitable for barrier-free construction

Properties:

• Quality-monitored in accordance with EN 1253-3
• With integrated gradient
• Shower Channels can be cut to length
• Floor tile structure 10 - 35 mm
• Shower Channels can be adjusted in height, slope and offset
• Easy to clean
• Water drainage above the bonded waterproofing
• Water drainage above the finished floor when using the sealing sleeve

Technical data:

• Height-adjustable drains: No
• Material: CrNiMo steel 1.4404 (DIN EN 10088)
• Shape: rectangular
• L / length (cm): 30-90 cm
• B / width (cm): 4.4 cm
• H / height (cm): 1 cm

Scope of delivery:

• Comb insert
• Inlet nozzle with equalising ring
• Suction cup
• Sealing sleeve

To be ordered additionally (see recommendation)

• Shell kit for Shower Channels from the CleanLine range
