description
- For installation in partial-height or room-height pre-wall installation
- For installation in room-high installation wall
- For installation in Duofix system wall
- Suitable for floor construction 0 - 20 cm
- Dry construction element
- Self-supporting
- Frame powder coated, color blue
- Frame with holes ø 9 mm for fastening in wood stud construction
- Ceramic fastening M12, fastening distance 18 cm or 23 cm
- Foot rests with cm grid marking, non-slip, height adjustable, galvanized
- Foot plate rotatable, for installation in UW50 and UW75 profiles
- Wall-mounted toilet bow depth-adjustable in 8 positions
- UP320 concealed cistern with front actuation, 25 years spare parts guarantee
- UP cistern for tool-free installation and tool-free service work
- Flush-mounted cistern with condensation water insulation
- Flush volume adjustable
Included in delivery:
- Universal water connection R1/2" with integrated angle valve and handwheel (MeplaFix capable)
- Empty water supply pipe for Balena shower toilet
- Protective plug
- 2 threaded rods M12 for ceramic fastening
- PE connection set ø 90mm
- PE wall-toilet bend, ø 90mm
- PE transition piece, ø 90 / 110mm
- Fixing material
*non-binding price quotation of the manufacturers
**Badquadrat Shop Price without additional discount
**Badquadrat Shop Price without additional discount
Artikel zum Warenkorb hinzugefuegt
Geberit Duofix wall-hung WC, 112cm, with Sigma concealed cistern UP320
In stock (2 Days)
