Ideal Standard Tonic II concealed bath mixer, intrinsically safe in accordance with DIN EN 1717, chrome

• Ideal Standard Tonic II
• 1 x Single lever concealed bath mixer DN 15
• Kit 2 for final assembly
• Intrinsically safe according to DIN EN 1717
• flow rate at 3 bar: 24 l/min
• Metal handle with red/blue marking
• Karree rosette
• Stainless steel cartridge ratio
• Cartridge Ø 47 mm
• CLICK cartridge with ceramic sealing discs
• DICHT-FIX system: separate sealing of each opening for optimum protection of the structure against moisture and water
• Hot water temperature limiter
• Noise behaviour DIN 4109: Group 1
• Service life: DIN EN 817
• Weight 1,200 kg

Required accessories, please order separately:

• Concealed kit 1 Easy-Box for single lever mixer and thermostats for installation - A1000NU

Optional accessories ( available separately )

• Spacer frame for flat rosette soft-edge 163x163 mm for single-lever mixer and thermostats flush-mounted kit 2 (20mm) - A6678AA
• Extension for single-lever mixer and thermostats flush-mounted kit 2 (20mm) - A960704NU
• Extension for single-lever mixer and thermostats flush-mounted kit 2 (20mm) - A962476NU
• Back-to-back cartridge for single-lever mixer (for reversed connections) - A963462NU
• Pre-shut-off for Easy-Box - A960706NU
