BetteSensory waste and overflow set

• BetteSensory
• 1 x waste and overflow set
• 280 x 150 x 130 mm
• Material: plastic
• Drain diameter: 52 mm
• Construction height: 115 mm

Scope of delivery

• Control box
• 12 V power supply unit
• emergency battery
• Two 8 m long control cables

Technical note:

• Drain and overflow set without visible overflow.
• The overflow function is ensured by a pressure sensor integrated into the drain set, which detects the water column in the bathtubs.
• The drain set is supplied with a control box, a 12 V power supply unit, an emergency battery and two 8 m long control cables.
• The control box, including the emergency battery and the power supply unit, must be integrated into two accessible flush-mounted sockets outside the bath using the 8 m cable.
• The power connection requires a 230 V power connection there.
• The control cable must be laid from the flush-mounted box to below the bath to connect to the fitting.
