Geberit pipework set for Geberit CleanLine Shower Channels, for screed height at inlet 65-90 mm, d=40mm
- Item No. 154.152.00.1
- Further information
RRP 368,78 €*
141,99 €
**
Shipping index: 150 Points
incl. 19% VAT in addition
Recommended products
Customers also bought
Further information
Product information
- Geberit
- 1 x shell kit for Geberit CleanLine Shower Channels
- For installation inside buildings
- For the drainage of Geberit Shower Channels from the CleanLine range
- For floor structures 65 - 90mm
- For bonded waterproofing
- For collecting the waste water from a single shower head
- For installation with a very low floor structure
Properties:
- Deviating from the requirements of EN 1253, the siphoning height is only 30mm
- Minimum screed height at the inlet 65mm
- Pre-assembled sealing fleece, 10cm all round, for connecting sealing systems
- EPS main body for sound decoupling and odour trap absorption
Technical data:
- Water trap height (mm): 30 mm
- Height-adjustable drains: Yes
- Shape: Others
- DN / nominal diameter: 40
- d, ø / outer diameter (mm): 40 mm
- Drainage capacity (l/s): 0.4 l/s
- L / length (cm): 30 cm
- L1 / length (cm): 35.8 cm
- B / width (cm): 13 cm
- H / height (cm): 6.5 cm
- H1 / height (cm): 6.5-17.5 cm
- h / partial height (cm): 3.2 cm
Scope of delivery:
- Protective building ceiling with skimming edge
- Thin-bed attachment
- Odour trap made of PE-HD
- Fastening material
To be ordered additionally (see recommendation)
- Shower Channels from the CleanLine range
